　技術參數


	● 壓力范圍：6000 PSIG(410 BARG)@110°F(38℃) ● 溫度范圍：-65°F至450°F(-45℃至232℃)用PTFE密封 1200°F(648℃)用GRAFOIL密封 ● 閥體材質：316不銹鋼、碳鋼、黃銅和400號合金

　尺寸目錄

Basic Part No.			Orifice	Cv	End Connections	Dimensions
Basic Part No.			Orifice	Cv	Inlet & Outlet	L	L1	L2	L3	M	M1	M2	N1	N2	P	Q	S Straight	S Angle	T
GB1	F	-2N-	4.0	0.35	1/8"Female NPT	50.8	25.4	23.0	25.4	32.6	27.8	32.6	9.6	9.6	45	15.1	77.8	82.6
	F	-4N-			1/4"Female NPT	52.4	26.2	23.0		32.6
	M	-4N-			1/4"Male NPT	50.8	25.4	25.4		35.0
	MF	-4N-			1/4"Male NPT/1/4"Female NPT	52.4	26.2	23.0		32.6
	H	-6M-			6mm Hy-Lok	61.9	31.0	29.4	37.3	38.9		27.8						77.8
	H	-4T-			1/4"Hy-Lok	61.9	31.0	29.4	37.3	38.9
	SW	-4T-			1/4"Tube Weld	46.0	23.0	22.3	30.2	31.8									7.2
	H	-8M-			8mm Hy-Lok	61.9	31.0	29.4	37.3	38.9
GB2F	F	-4N-	6.4	0.86	1/4"Female NPT	57.2	28.6	25.4	28.6	38.1	34.1	37.3	12.7	12.7	64	19.9	93.7	96.9
	F	-6N-			3/8"Female NPT	57.2	28.6	25.4	28.6	38.1		37.3						96.9
	H	-10M-			10mm Hy-Lok	73.0	36.5	33.3	39.7	46.1		34.2						93.7
	H	-6T-			3/8"Hy-Lok	73.0	36.5	32.5	42.9	45.3		31.0						90.5
	H	-12M-			12mm Hy-Lok	77.8	38.9	35.7	42.1	48.4		34.2						93.7
	H	-8T-			1/2"Hy-Lok	77.8	38.9	34.9	42.1	47.6		34.2						93.7
	SW	-4P-			1/4"Pipe Weld	57.2	28.6	25.4	28.6	38.1		37.3						93.7	9.6
	SW	-6T-			3/8"Tube Weld				28.6			37.3						93.7	8.0
	SW	-8T-			1/2"Tube Weld				25.4			35.7						95.3	9.6
GB3	F	-8N-	11.0	2.2	1/2"Female NPT	79.4	39.7	33.30	39.7	50.8	46.1	50.8	15.9	17.5	89	26.2	121.5	126.2
	F	-12N-			3/4"Female NPT	82.6	41.3	-	-	-	48.4	-	19.9	-			121.5	126.2
	F	-16N-			1"Female NPT	92.1	46.0	-	-	-	54.0	-	25.4	-			123.9	-
	MF	-8N-			1/2"Male NPT/1/2"Female NPT	79.4	39.7	33.3	39.7	50.8	46.0	50.8	15.9	17.5			129.4	-
	MF	-12N-			3/4"Male NPT/3/4"Female NPT	82.6	41.3	-	-	-	48.4	-	19.9	-			121.5	126.2
	MF	-16N-			1"Male NPT/1"Female NPT	92.1	46.0	-	-	-	54.0	-	25.4	-			123.9	-
	H	-12N-			12mm Hy-Lok	100.0	50.0	-	-	-	46.0	-	15.9	-			129.4	-
	H	-8T-			1/2"Hy-Lok			43.7	53.2	61.1		47.6		17.5			121.5	-
	H	-12T-			3/4"Hy-Lok			43.7	53.2	61.1		47.6		17.5			121.5	123.1
	H	-16T-			1"Hy-Lok			-	-	-	47.6	-	17.5	-			123.1	-	9.6
	SW	-8P-			1/2"Pipe Weld	79.4	39.7	33.3	39.7	50.8	47.6	50.8	17.5	17.5			123.1	126.2	9.6
	SW	-8T-			1/2"Tube Weld			33.3	42.9	50.8	46.0	47.6	15.9	17.5			121.5	123.1	11.1
	SW	-12T-			3/4"Tube Weld			-	-	-	46.0	-	15.9	-			121.5	-	-
